POE UPS for WiFi router CCTV camera CPE

Short Description:

POE UPS 为WiFi router , CCTV camera , CPE, Wireless AP, Wire antenna,可以为家中的DC、POE等设备供电,产品拥有USB5V/DC9V12V/POE24V输出口。POE UPS is a WiFi router, CCTV camera, CPE, Wireless AP, Wire antenna. It can power DC, POE and other equipment at home. The product has USB5V/DC9V12V/POE24V output ports.

Product Detail


Product Tags

Product Display



product name MINI DC UPS Product number POE04
Input voltage 110-240V recharging current 8.4V415mA
charging time 11.3H output voltage current 9V1A,12V1A ,5V1.5A,24V0.45A /48V 0.16A
Output Power 7.5W~14W Maximum output power 14W
protection type Overcurrent protection, short circuit protection Working temperature 0℃~45℃
Input Features AC110-240V Switch mode Button switch, automatic power on when power is turned on
Output port characteristics DC5525 9V,12V,USB5V,POE24V/48V Indicator light explanation When charging, the LED flashes in 25% increments, and when fully charged, the four lights are always on; when discharging, the four lights go out in 25% decrements until the four lights flash 10 times and then shut down.
Product capacity 7.4V/4000mAh/29.6Wh Product color White/Black
Single cell capacity 3.7V/4000mAh Product Size 159*77*27.5mm
Cell quantity 2 Packaging accessories 5525转5525DC线*1,AC线*1(美/英/欧规自选)
Cell type 21700 Series and parallel mode 2S1P
Cell cycle life 500 box type airplane box


Product Details


A multi-output POE UPS with 1 USB output port, 2 DC output ports, and 1 POE output port. It can power ONU+WiFi router+CPE, Wireless AP+WiFi router and other combined devices, solving the problem of powering multiple devices. Equipment power supply problem.

The product has a 21700 battery capacity of 8000mAh, which can power POE equipment for more than 2 hours. Many customers purchase the product to power ONU+WiFi router+CPE equipment together.


UPS can choose two POE output voltages of 24V/48V. The connection method is very simple. You only need to connect the POE line to the device and then connect it to the UPS poe output port to power the device. It is simple and easy to use

Application Scenario

POE UPS can be used in any scenario, such as home, office, and supermarket. You don’t have to worry about the weight of the UPS being too heavy to hold. This UPS is compact and easy to carry.
